TRW DF4197 Brake Disc for MINI

Reference DF4197

Brand TRW

MINI ➤ MINI | MINI Convertible

€39.57

€35.61 Save 10%

Tax included

Quantity

Available in warehouses

W01: 16 qty

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Product Details

Reference DF4197

EAN13 3322937320950

MPN DF4197

In stock 16 Items

Condition New

Data sheet

Brake Disc Thickness [mm]: 22
Thread Size: 15
Minimum thickness [mm]: 20,4
Colour: black
Machining: High-carbon
Outer Diameter [mm]: 276
Number of Holes: 4
Centering Diameter [mm]: 64,2
Bolt Hole Circle Ø [mm]: 100
Surface: Painted
Test Mark: E190R-02C0176/0031
Height [mm]: 44,2
Brake Disc Type: Vented

A.B.S.: 17349
A.P.: 24220
A.P.: 24220V
ACDelco: AC2576D
APEC: DSK2060
ATE: 24.0122-0204.1
ATE: 24.0322-0204.1
ATE: 24112202041
BENDIX - OLD: 562139B
BENDIX - OLD: 562139BC
BLUE PRINT: ADG04374
BORG & BECK: BBD4256
BOSCH: 0 986 478 606
BOSCH: 0 986 479 B39
BOSCH: 0 986 AB6 416
BOSCH: F 005 X14 040
BOSCH: F 026 A01 226
Brake ENGINEERING: DI956134
BREMBO: 09.8655.10
BREMBO: 09.8655.11
BREMBO: 09.8655.20
BREMBO: 09.8655.21
BREMBO: 09.8655.75
CAR: 142084
CAR: HPD084
DBA Australia: DBA542
DELPHI: BG3661
DELPHI: BG3661C
FEBI BILSTEIN: 23115
FEBI BILSTEIN: 43858
FERODO: DDF1127
FERODO: DDF11271
FERODO: DDF1127C
FERODO: DDF1127C1
FERODO: DDF1127X
FERODO: DRF1127
FIRST LINE: FBD1246
FTE: 9072281
FTE: 9082189
FTE: 9082562
FTE: BS5312
GIRLING: 6041971
HELLA: 8DD 355 120-611
HELLA: 8DD 355 120-612
HELLA: 8DD 355 131-971
HELLA: 8DD 355 131-981
HELLA: 8DD355107781
HELLA: 8DD355107791
HELLA PAGID: 8DD355120611
HELLA PAGID: 8DD355120612
HELLA PAGID: 8DD355131971
HELLA PAGID: 8DD355131981
JURID: 562139J
JURID: 562139JC
LEMFÖRDER: 27178 01
LPR: B2008V
LPR: B2008VR
MAGNETI MARELLI: 353610654240
METELLI: 23-0666C
METZGER: 230666
MEYLE: 315 521 0024
MEYLE: 315 521 0024/PD
MEYLE: 3155213027
MEYLE: 3155213027PD
MGA: D1402
MINI: 1502891
MINI: 34111502891
MINI: 34116774984
MINI: 6774984
MINTEX: MDC1129
MINTEX: MDK0182
National: NBD1125
NK: 204016
OPTIMAL: BS7450
OPTIMAL: BS7450C
PAGID: 50324
PAGID: 50324PRO
PEX: 140767
PILENGA: V811
QH Benelux: 58006
QUINTON HAZELL: 662410
QUINTON HAZELL: BDC5312
QUINTON HAZELL: BSF5312
REMSA: 662410
ROADHOUSE: 662410
ROULUNDS RUBBER: D2576
ST-TEMPLIN: 0311021490
ST-TEMPLIN: 0311021495
SWAG: 11923115
TEXTAR: 92107500
TEXTAR: 92107503
TEXTAR: 92107505
TEXTAR: 92262400
TEXTAR: 92262403
TEXTAR: 92262405
TRISCAN: 812011150
TRISCAN: 812011150C
TRUSTING: DF825
VALEO: 186762
WOKING: P662410
ZIMMERMANN: 150.3400.20
ZIMMERMANN: 150340000
ZIMMERMANN: 150340050

MINI

MINI (R50, R53) Cooper (2001 - 2006) 1598 ccm, 85 kw, 116 hp [Fitting Position :: Front Axle]

MINI (R50, R53) Cooper S (2002 - 2006) 1598 ccm, 120 kw, 163 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI (R50, R53) Cooper S (2004 - 2006) 1598 ccm, 125 kw, 170 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI (R50, R53) One (2001 - 2006) 1598 ccm, 66 kw, 90 hp [Fitting Position :: Front Axle, Vehicle Equipment :: for vehicles without sports package]

MINI (R50, R53) One (2003 - 2006) 1398 ccm, 55 kw, 75 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI (R50, R53) One D (2003 - 2006) 1364 ccm, 55 kw, 75 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI (R50, R53) One D (2003 - 2006) 1364 ccm, 65 kw, 88 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI (R50, R53) S Works (2003 - 2005) 1598 ccm, 149 kw, 203 hp [Braking System :: for vehicles with reinforced brakes, Fitting Position :: Front Axle]

MINI (R50, R53) Works (2003 - 2006) 1598 ccm, 155 kw, 210 hp [Braking System :: for vehicles with reinforced brakes, Fitting Position :: Front Axle]

MINI Convertible (R52) Cooper (2004 - 2008) 1598 ccm, 85 kw, 116 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]

MINI Convertible (R52) Cooper S (2004 - 2008) 1598 ccm, 125 kw, 170 hp [Fitting Position :: Front Axle, Suspension :: for vehicles without heavy duty suspension]

MINI Convertible (R52) Cooper S (2004 - 2007) 1598 ccm, 120 kw, 163 hp [Fitting Position :: Front Axle]

MINI Convertible (R52) One (2004 - 2007) 1598 ccm, 66 kw, 90 hp [Construction Year to :: 200707, Fitting Position :: Front Axle, Suspension :: for vehicles without sports suspension]
